Product Overview

AL-E090C RLC RESONANCE TRAINER (WITH INBUILT FUNCTION GENERATOR WITH FREQUENCY COUNTER AND DIGITAL METERS)


Discription:

SCOPE OF LEARNING:

  • Study of RLC Resonance In Series
  • Study of RLC Resonance In Parallel

TECHNICAL SPECIFICATIONS:

Digital Meters:

  • Ammeter 20mA AC.
  • Frequency Counter Up to 40MHz.

Sine Wave Generator:

  • 0-100KHz Sine Wave Generator

Components are mounted on the panels are:

  • 3 Nos. of Resistors selected by Rotary Switch.
  • 3 Nos. of Capacitors selected by Rotary Switch.
  • 3 Nos. of Inductors selected by Rotary Switch.

SALIENT FEATURES:

  • Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and      symbols.
    • Fuse for Short Circuit protection
    • Instruction manual.
    • Connections are brought out through 4mm Colored Sockets.
    • Patch Cords 4mm.
    • The trainer is housed in ABS Plastic cabinet.
    • Size of the trainer set 15”x11”

OPTIONAL ACCESSORIES:

  • No
